End Mills > APX4000_INCH

End Mills

APX4000_INCH

  • Air coolant through.
  • Low resistance insert and high rigidity body.
  • Ideal chip control.
  • High wall accuracy can be produced by using this cutter and unique insert geometry.

Type1 [Outspread]

Type2 [Outspread]

Type3 [Outspread]

Type4 [Outspread]

Type5 [Outspread]

Type6 [Outspread]

Type7 [Outspread]

  1 2
Order Number Type CAD Type of Coolant Hand Name of Grade Grade Stock
APX4000UR121FA12SA Type4 CAD R
APX4000UR121FA12SB Type4 CAD R
APX4000UR121SA12SA Type1 CAD R
APX4000UR162AM12A35 Type7 CAD R
APX4000UR162FA16SA Type4 CAD R
APX4000UR162FA16SB Type5 CAD R
APX4000UR162SA12SA Type3 CAD R
APX4000UR162SA16LA Type2 CAD R
APX4000UR162SA16LB Type2 CAD R
APX4000UR162SA16SA Type2 CAD R
APX4000UR182AM12A35 Type7 CAD R
APX4000UR202FA20SA Type4 CAD R
APX4000UR202FA20SB Type5 CAD R
APX4000UR202SA20LA Type2 CAD R
APX4000UR202SA20LB Type2 CAD R
APX4000UR202SA20SA Type2 CAD R
APX4000UR203AM16A40 Type7 CAD R
APX4000UR203FA20SA Type4 CAD R
APX4000UR203FA20SB Type5 CAD R
APX4000UR203SA20LA Type2 CAD R
