CB
(Micro Mini Twin)

CB08RS-B EDP:492535

Product Information

  • Solid carbide type with 2 cutting edges.
  • Each boring bar comes in two types, with or without breaker.

Type   [Outspread ]

Type   [Outspread ]

Diameter (Unit)
Name of Grade Carbide
Grade VP15TF
Sales unit 1
Hand R
Stock
Unit of Length M
DMIN 8.2
DCON 8
L20 15
LF 95
LDRED 24
WF 4
H 7.2
WF2 0.85
RE 0.05
Peripheral effective cutting edge count: ZEFP 1
Classification of Grades
Coated・Carbide MS7025
Coated・Carbide MS9025
Non-coated・Carbide TF15
2D Model (DXF)
CAD data name Download
CB08RS-B
CAD

3D Detail Model (STP,STL)
CAD data name Download
CB08RS-B
CAD CAD

Stock

:Inventory maintained.
:Non stock, produced to order only.
:Inventory maintained. To be replaced by new products.
:Inventory maintained in Japan.
