Combinação ideal: inserto CVD na periferia e PVD no centro.
Corpo de alta rigidez permite furação 6xD.

The actual product may differ from the displayed image.
For details, please check the dimensions below.

Diâmetro ()

Metric	Inch
mm	in
microns *	microinches *
N	lbf
deg	deg
MPa	psi
N/m	lbf/in
Nm	lbf-in
kg	lbs
rpm	rpm

Estoque

Unidade de comprimento

M

DC

14

DCON

20

DCSFMS

25

OAL

135

LPR

92

LU

70

S10

0.6

LBX

77

ld

5

Cutting item count: CICT

2

Peripheral effective cutting edge count: ZEFP

2

Effective Cutting Edge

1

Tipo de refrigeração

Interno

Modelo 2D (DXF)
Nome do arquivo CAD	Download
