Face Cutter >AJX_INCH >AJXU09R0205

Face Cutter

AJX09_INCH
（MULTI FUNCTIONAL MILLING）

AJXU09R0205 EDP:428218

METRIC Products
Shape Series Tooling Sheet Feature Cutting Edge Angle
AJX
  • Suitable for high feed cutting.
  • Standardization of coolant holes.
  • Special insert design with the use of 3 cutting edges.
  • High rigidity due to double clamp structure.

AJX_MM
  • High rigidity due to double clamp structure.
  • Suitable for high feed cutting.
  • Special insert design with the use of 3 cutting edges.
  • Standardization of coolant holes.


Product Information

  • Special insert design with the use of 3 cutting edges.
  • High rigidity due to double clamp structure.
  • Suitable for high feed cutting.

The actual product may differ from the displayed image.
For details, please check the dimensions below.

Type   [Outspread ]

Type   [Outspread ]

Diameter (Unit)
Metric Inch
mm in
microns * microinches *
N lbf
deg deg
MPa psi
N/m lbf/in
Nm lbf-in
kg lbs
rpm rpm

* Only ADJAR,ADJRR
Sales unit 1
Hand R
Stock
Unit of Length I
AZ .039
DC 1.606
DCX 2
DCON .75
DCSFMS 1.875
DAH .415
DCCB .6
RMPX 1.1
L8 .187
LF 2
CBDP .748
KWW .313
APMX .079
GAMP +8°
GAMF -6°
Peripheral effective cutting edge count: ZEFP 5
2D Model (DXF)
CAD data name Download
AJXU09R0205
CAD
